Toro GrandStand 72509 23.5hp Kawasaki FX Engine 60″ FAB Deck Mower

Toro GrandStand 72509 23.5hp Kawasaki FX Engine 60″ FAB Deck Mower

• Conserves space to get more machines on your trailer, or allows for a smaller trailer and lighter load.
• Foldable operator platform instantly converts the machine to a walk-behind.
• Great visibility for easy navigation around obstacles, protecting the operator, mower, and property.
• Quick access to the engine, hydros and controls with the easy removal of the fuel tank.
• No hydraulic hoses, reduced parts, no routine greasing and simplified design to save you time.
• Self-adjusting suspension and a larger platform area for a more secure stance on sloped terrain.
• The TURBO FORCE^® cutting deck is built to withstand the long, tough days on the job.
• 10.5 gallon fuel tank for fewer fill-ups. Transparent tank make it easy to gauge the fuel level.
• A wide stance and optimal balance enhance hillside stability and control.
• Horizon360^® Business Management Software. Work More Efficiently. Run More Profitably.

Specifications

Adjustable Discharge Baffle	Standard, Tools-Free
Air Filter	Heavy-Duty Canister Air Cleaner
Anti Scalp Wheels	Standard
Blade Tip Speed	18,500 ft/min / 5,638 m/min
Blades	0.204 in. (0.5 cm) heat-treated steel
Box Dimensions	90 in. x 70 in. x 52 in. / 228.6 cm x 117.8 cm x 132.1 cm
CARB Compliant	Not CARB Compliant
Carrier Frame	3 in. x 1.5 in. x 12 gauge (7.6 cm x 3.8 cm x 12 gauge)
Caster Tires	11 in. x 4 in. – 5 in. (27.9 cm x 10.2 cm – 12.7 cm) Flat-Free Semi-Pneumatic
Clutch	Electromagnetic
Comfort Platform	Foldable Operator Platform with Suspension
Controls	Twin lever
Deck Design	7-gauge 60″ (152.4 cm) TURBO FORCE® w/bull-nose bumper
Deck Material	7 Gauge Steel
Deck Size	60 in / 152 cm
Discharge Chute	Rubber
Drive System	Unitized Pumps 10cc rev Wheel Motors 10 cir
Drive Tires	20 in. x 10.5 in. – 8 in. (50.8 cm x 26.7 cm – 20.3 cm)
Engine	23.5 hp* Kawasaki FX730V 726 cc
Engine Brand	Kawasaki
Engine Displacement (cc)	726 cc
Engine Horsepower	23.5 hp
Forward Ground/Transport Speed	Up to 10.0 mph / 16.0 kph
Front Bumper	Reinforced Bull-Nose
Fuel Capacity	10.5 gal. / 39.7 L / 42 Qt.
Fuel Type	Gasoline
Height of Cut	1.5 – 5.0 in. / 3.8 – 12.7 cm
Hour Meter	Standard
Hydraulic Fluid	Premium synthetic
Product Type	Stand-On Mowers
Product Use	Commercial
Spindle Bearings	Maintenance-free
Spindle Housing	9 in / 22.9 cm Diameter Cast Aluminum
Start Type	Electric
Steering Controls	Twin Lever
Weight	960 lbs / 435.4 kg

Disclaimer

*23.5 HP gross at 3,600 RPM SAE J1940 and SAE J2723, as rated by Kawasaki®. As configured to meet safety, emission and operating requirements, the actual engine horsepower on this mower may be significantly lower. Accessory List (Not Included)

Model/Part #	Description
139-6655	Recycler Mulch Kit
